Thread: Metric, PG, G(PF), and NPT thread
Materials: UL approved Nylon PA66 (Flammability UL 94V-2) for A. C. F parts, (Accept to make flammability UL 94V-0 ); EPDM rubber for B. D parts, (Also accept to make super rubber: resist high temperature rubber, resist strong acid/alkali,etc).
Protection degree: IP68
Working temperature: -40℃ to 100℃
Features: The claws and seals of excellent design, sealing nut have a “click”sound and re-open, can hold cable firmly and have a wider cable range. Resistant to salt water, weak acid, alcohol, oil, grease and common solvency.
Colours: Black(RAL9005)、gray(RAL7035),other color available upon request.
Thread |
Item.No. |
Cable Range
Ф(mm)
|
Thread O.D.
C1(mm)
|
Thread Length
C2(mm)
|
Spanner Size
A&F(mm)
|
Std.Pkg
(pcs)
|
M12 x 1.5
|
SXL-M12A -5.5
|
3-5.5
|
12
|
8.5
|
18/19
|
50
|
SXL-M12A -8
|
4.5-8
|
12
|
8.5
|
18/19
|
50
|
M16 x 1.5
|
SXL-M16A -7
|
4-7
|
16
|
15
|
22/22
|
50
|
SXL-M16A -10
|
6-10
|
16
|
15
|
22/22
|
50
|
M20 x 1.5
|
SXL-M20A -11
|
7-11
|
20
|
15
|
27/27
|
20
|
SXL-M20A -14
|
9-14
|
20
|
15
|
27/27
|
20
|
M25 x 1.5
|
SXL-M25A -16
|
12-16
|
25
|
15
|
33/33
|
20
|
SXL-M25A -18
|
14-18
|
25
|
15
|
33/33
|
20
|
PG7
|
SXL-PG7A -5.5
|
3-5.5
|
12.5
|
8
|
17/19
|
50
|
SXL-PG7A -8
|
4.5-8
|
12.5
|
8
|
17/19
|
50
|
PG9
|
SXL-PG9A -5.5
|
3-5.5
|
15.2
|
8.2
|
22/19
|
50
|
SXL-PG9A -8
|
4.5-8
|
15.2
|
8.2
|
22/19
|
50
|
PG11
|
SXL-PG11A-7
|
4-7
|
18.6
|
10
|
24/22
|
50
|
SXL-PG11A-10
|
6-10
|
18.6
|
10
|
24/22
|
50
|
PG13.5
|
SXL-PG13.5A-8.8
|
4-8.8
|
20.4
|
10
|
27/24
|
20
|
SXL-PG13.5A-12.5
|
7-12.5
|
20.4
|
10
|
27/24
|
20
|
PG16
|
SXL-PG16A-11
|
7-11
|
22.5
|
10.8
|
30/27
|
20
|
SXL-PG16A-14
|
9-14
|
22.5
|
10.8
|
30/27
|
20
|
PG21
|
SXL-PG21A-16
|
12-16
|
28.3
|
12
|
36/33
|
20
|
SXL-PG21A-18
|
14-18
|
28.3
|
12
|
36/33
|
20
|
G(PF)1/4"
|
SXL-G1/4A-5
|
3-5.5
|
13.157
|
8.5
|
19/19
|
50
|
SXL-G1/4A-8
|
4-8
|
13.157
|
8.5
|
19/19
|
50
|
G(PF)3/8"
|
SXL-G3/8A-7
|
4-7
|
16.662
|
15
|
22/22
|
50
|
SXL-G3/8A-10
|
6-10
|
16.662
|
15
|
22/22
|
50
|
G(PF)1/2"
|
SXL-G1/2A-9
|
4-8.8
|
20.955
|
15
|
27/24
|
20
|
SXL-G1/2A-12.5
|
7-12.5
|
20.955
|
15
|
27/24
|
20
|
G(PF)3/4"
|
SXL-G3/4A-13
|
7-13
|
26.441
|
15
|
36/33
|
20
|
SXL-G3/4A-17.5
|
12.5-18
|
26.441
|
15
|
36/33
|
20
|
